ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm

    Buy cheap ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm from wholesalers

    Buy cheap ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm from wholesalers
    • Buy cheap ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm from wholesalers
    • Buy cheap ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm from wholesalers
    • Buy cheap ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm from wholesalers

    ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm

    Ask Lasest Price
    Brand Name : TISCO/JISCO/BAOSTEEL
    Model Number : 410S
    Certification : ISO, CE, BV SGS MTC
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 3,000 TONS/MONTH
    Delivery Time : 22 work days
    • Product Details
    • Company Profile

    ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm

    ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm


    410S STAINLESS STEEL ALLOY

    UNS: S41008
    EN-DIN: 1.4510

    Printable PDF: 410S Stainless Steel Alloy Data Sheet

    410S Stainless Steel is a non-hardening modification of Type 410. A small aluminum addition minimizes austenite formation at high temperatures, thereby restricting the alloy’s ability to harden. The result is a soft, ductile condition when the material is rapidly cooled from above the critical temperature. This non-hardening characteristic also retards formation of hardening cracks when the steel is welded. The alloy is completely ferritic in the annealed condition.

    Nominal Composition

    C:0.080 max
    Mn:1.0 max
    P:0.040 max
    S:0.030 max
    Si:1.00 max
    Cr:11.50 – 13.50
    Ni:0.60 max
    Ti:0.20 max
    Fe:BAL

    Physical Properties
    At 70°F (At 20°C)

    Density
    0.280 lb./in³ / (7.73 kg/m³)

    Modulus of Elasticity (E)
    29.0 x 10³ ksi / (200 x 10³MPa)

    Coefficient of Expansion
    9.6 x 10-6 microinches/in.-°F (32-212°F) / (17.3 μm/m-°C) (0-100°C)

    Electrical Resistivity
    23.7 μ ohm.in / (60.0 μ ohm.cm)

    Thermal Conductivity
    15.6 Btu-in./ft.²hr.-°F (100°C)/ (26.9 W/m-K) (100°C)

    Applicable Specifications

    ASTM A240

    Typical Mechanical Properties – Typical Room Temperature Mechanical Properties

    Typical mechanical properties are based on AK source, ASTM A240

    Condition
    Annealed

    Tensile Strength (UTS)
    65 ksi (448 MPa)

    0.2% YS
    40 ksi (276 MPa)

    Elongation% in 2” (50.8 mm)
    25%

    Hardness Rockwell
    75 HRBW

    ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mmASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mmASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mmASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm

    ASTM A240 AISI410S SUS410S 06Cr13 Stainless Steel Plate 3-30mm 1500*6000mm


    FAQ:
    Q:What about product prices information?
    A:Prices various according to periodic price changes of raw materials.
    Q:What is your terms of payment ?
    A:Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment or based on BL copy or LC at sight.
    Q:Do you provide custom made Products service?
    A: Yes,if you have your own design , we can produce according to your specification and drawing.
    Q:Can I go to your factory to visit?
    A:Of course, we welcome customers from all over the world to visit our factory.
